cpvc Pipes & Fittings
Nikolas Pipes & Fittings is proud to offer a premium selection of CPVC pipes and fittings, meticulously crafted to meet the demanding requirements of modern plumbing systems. We are manufacturing CPVC pipes under the ISI standard in both SDR-13.5 and SDR-11 and CPVC fittings made under the standard ASTM-D2846 in SDR-11. Our full range of pipe products is rigorously tested and ISI certified, ensuring compliance with the highest quality and safety requirements. Our Chlorinated Polyvinyl Chloride (CPVC) products are engineered to deliver superior performance, durability, and safety, making them the ideal choice for residential, commercial, and industrial applications.
CPVC ISI PLUMBING PIPE
CPVC ASTM D2846 PLUMBING Fittings
CPVC ASTM D2846 PLUMBING Fittings
Product Specification
| Pipe Standard | As Per IS : 15778 : 2007 SDR - 13.5, SDR - 11 |
|---|---|
| Fittings Standards | As Per ASTM D 2846 SDR - 11 |
| Material | C-PVC Compound |
| Standard Length | 3 meters Pipes / 5 meters Pipes |
| Solvent Cement | Heavy Duty |
| Colour | Off White |
| Pressure Class | Pipe SDR-11 & SDR-13.5, Fittings SDR-11 |
| Range of Pipes | From ¾ " to 2" |
| Range of Fittings | From ¾ " to 2 |
Salient Features & Benefits
- Low thermal expansion
- High Corrosion Resistance
- Chemical Resistance
- Suitable for hot & cold water
- Lower Bacterial growth
- Easy Instillation
- Tough and Rigid material
- Maintenance Free
- Strong and light weight
- Fire Safe material
- UV Stabilized
| Nominal Bore | Nominal Size | Nominal Outside Diameter | SDR-11 Wall Thickness | Working Pressure at | SDR-13.5 Wall Thickness | Working Pressure at | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Minimum | Maximum | 27 C | 82 C | Minimum | Maximum | 27 C | 82 C | ||||
| Inch | mm | mm | mm | mm | Kg / Cm2 | mm | mm | Kg / Cm2 | |||
| ½ | 15 | 15.9 | 1.7 | 2.2 | 28.10 | 7.0 | 1.4 | 1.9 | 21.80 | 5.5 | |
| ¾ | 20 | 22.2 | 2.0 | 2.5 | 28.10 | 7.0 | 1.7 | 2.2 | 21.80 | 5.5 | |
| 1 | 25 | 28.6 | 2.6 | 3.1 | 28.10 | 7.0 | 2.1 | 2.6 | 21.80 | 5.5 | |
| 1 ¼ | 32 | 34.9 | 3.2 | 3.7 | 28.10 | 7.0 | 2.6 | 3.1 | 21.80 | 5.5 | |
| 1 ½ | 40 | 41.3 | 3.8 | 4.3 | 28.10 | 7.0 | 3.1 | 3.6 | 21.80 | 5.5 | |
| 2 | 50 | 54.0 | 4.9 | 5.5 | 28.10 | 7.0 | 4.0 | 4.6 | 21.80 | 5.5 | |
